ETEL Doc. - Operation & Software Manual # DSC2P 903 / Ver. F / 3/6/05 Chapter A: Internal functioning & architecture
Operation & Software Manual
Direct Drives & Systems 25
Example:
Remark: All the position controllers (slave axes) can be connected together. The only rule to respect is to
have 31 slaves maximum.
5.3 Multi-axis configuration with micro-master
In this configuration, the controllers are also linked in daisy-chain. The master is a DSC2P or DSC2V called
micro-master (and written µ-master) with whom the PC communicates via the EBL2. The µ-master can also
have a sequence which send commands to other controllers. It always has the axis number 0. The other axes
are called slaves. All axes are linked together by the Turbo-ETEL-Bus also called TEB (ETEL proprietary
protocol). One of the roles of the master is to dispatch the orders he receives from the PC or (sent by itself) to
the slaves. Each axis has a personal number, and if several axes are chained, every number must be different
from the others (from 0 to 30). It is then possible to link up to 31 axes.
The functioning mode is chosen with the MDE command which is an alias of parameter K170 (only available
on the DSC2P and DSC2V)
K Alias Value Comment
K170 MDE
0 Select slave mode (default mode)
1
Select
µ-master mode
ISA/PCI
port
Turbo-ETEL-Bus
TEB
TEB
TEB
DSMAX
or
DSTEB
in the PC
master
DSC2P
axis 0
slave
DSC2P
axis 1
slave
DSC2P
up to
31 axes
slave
Turbo-ETEL-Bus
TEB
TEB
TEB
DSCDP
slave
DSCDP
slave
DSCDP
up to
slave
Axis
0
Axis
1
Axis Axis
2 3
Axis Axis
28 29
DSMAX
or
DSTEB
in the PC
master
ISA/PCI
port
EBL2
Turbo-ETEL-Bus
TEB
TEB
TEB
DSC2P
or DSC2V
axis 0
µmaster
Controller
axis 1
slave
Controller
axis 2
slave
Controller
up to
30 axes
slave
The µ-master is a DSC2P or a DSC2V.
The slaves can be any controller
