ETEL Doc. - Operation & Software Manual # DSC2P 903 / Ver. F / 3/6/05 Chapter E: Appendixes
Operation & Software Manual
Direct Drives & Systems 341
18. Warnings reference lists
18.1 Warnings for DSC2P and DSC2V
18.2 Warnings for DSCDP
18.3 Warnings for DSCDL
M66 Displayed message Description
1 W I2T WARNING This warning occurs when M67 is greater than K85/2
2 W OVER TEMPERAT This warning occurs when the temperature of the controller is greater than 60°C
3 W INRUSH P.SUPPLY
Power supply inrush or power voltage too low (for rack version, it occurs when inrush signal on
d14 of JC15 is not at 0V; this signal is given by ETEL's power supply or must be given by the
user in case of another power supply)
4 W OVER VOLTAGE This warning occurs when the power voltage (Vpower) in volt is greater than K148/100
5 W ENCODE AMPLITU
This warning occurs when the amplitude of the analog encoder signals is too small (2x the
error)
6 TRACKING WARNING This warning occurs when the tracking error is greater than K30/2
8 W DIGIT. HALL Wrong value coming from the digital Hall sensor
9 WuCONTRO LSYNCHRO Loss of synchronization between the TEB signal and the controller interrupt
10 W UNDER VOLTAGE This warning occurs when the power voltage (Vpower) in volt is lower than K147/100
M66 Displayed message Description
1 W I2T WARNING This warning occurs when M67 is greater than K85/2
2 W OVER TEMPERAT This warning occurs when the temperature of the controller is greater than 60°C
3 W INRUSH P.SUPPLY
Power supply inrush or power voltage too low (for rack version, it occurs when inrush signal on
d14 of JC15 is not at 0V; this signal is given by ETEL's power supply or must be given by the
user in case of another power supply)
5 W ENCODE AMPLITU
This warning occurs when the amplitude of the analog encoder signals is too small (2x the
error)
6 TRACKING WARNING This warning occurs when the tracking error is greater than K30/2
8 W DIGIT. HALL Wrong value coming from the digital Hall sensor
9 WuCONTRO LSYNCHRO Loss of synchronization between the TEB signal and the controller interrupt
11 W OVER VOLTAGE This warning occurs when the power voltage is greater than 425V and no motor in Power On
M66 Displayed message Description
1 W I2T WARNING This warning occurs when M67 is greater than K85/2
2 W OVER TEMPERAT This warning occurs when the temperature of the controller is greater than 60°C
4 W OVER VOLTAGE This warning occurs when the power voltage (Vpower) in volt in greater than K148/100
5 W ENCODE AMPLITU
This warning occurs when the amplitude of the analog encoder signals is too small (2x the
error)
6 TRACKING WARNING This warning occurs when the tracking error is greater than K30/2
9 WuCONTRO LSYNCHRO Loss of synchronization between the TEB signal and the controller interrupt
10 W UNDER VOLTAGE This warning occurs when the power voltage (Vpower) in volt is lower than K146/100
