Etel DSC Series User Manual

Operation & Software Manual
204
Direct Drives & Systems
Chapter C: System functions ETEL Doc. - Operation & Software Manual # DSC2P 903 / Ver. F / 3/6/05
13.11.2 M61 monitoring (SD2)
13.11.3 M63 monitoring
bits # Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Bin. 101111
Hexa. 2F
Dec. 47
Available on DSC2P DSC2V DSCDP DSCDL DSCDM
Bit Value Bit definition Signification when bit = 0 When bit = 1
01
Sequence error
label pending
(label: 80)
Error handling routine being processed: If a controller error
appears, the sequence jumps to :80, to process the error handling
routine. Then, the bit will be set to 1 to avoid re-entering in the error
routine.
Not possible to execute the error
handling routine (under label : 80).
24
Position
captured on
digital input
This bit is reset when 1 is written in parameter K182.
This bit is set when the conditions
of the digital input allow the capture
of the position.
Bit definition (description when bit=1)
8 256 User bit 0, could be modified by trigger functions or by parameter K177
9 512 User bit 1, could be modified by trigger functions or by parameter K177
10 1024 User bit 2, could be modified by trigger functions or by parameter K177
11 2048 User bit 3, could be modified by trigger functions or by parameter K177
12 4096 User bit 4, could be modified by trigger functions or by parameter K177
13 8192 User bit 5, could be modified by trigger functions or by parameter K177
14 16384 User bit 6, could be modified by trigger functions or by parameter K177
15 32768 User bit 7, could be modified by trigger functions or by parameter K177
Available on DSC2P DSC2V DSCDP DSCDL DSCDM
Bit # Value Bit definition (description when bit=1) Corresponding to SD1 or SD2 bits
01User bit 0, could be modified by trigger functions or by parameter K177 SD2, bit# 8
12User bit 1, could be modified by trigger functions or by parameter K177 SD2, bit# 9
24User bit 2, could be modified by trigger functions or by parameter K177 SD2, bit# 10
38User bit 3, could be modified by trigger functions or by parameter K177 SD2, bit# 11
416User bit 4, could be modified by trigger functions or by parameter K177 SD2, bit# 12
532User bit 5, could be modified by trigger functions or by parameter K177 SD2, bit# 13
664User bit 6, could be modified by trigger functions or by parameter K177 SD2, bit# 14
7 128 User bit 7, could be modified by trigger functions or by parameter K177 SD2, bit# 15
8 256 User bit 8, could be modified by trigger functions or by parameter K177 -
9 512 User bit 9, could be modified by trigger functions or by parameter K177 -
10 1024 User bit 10, could be modified by trigger functions or by parameter K177 -
11 2048 User bit 11, could be modified by trigger functions or by parameter K177 -
12 4096 User bit 12, could be modified by trigger functions or by parameter K177 -
