Operation & Software Manual
342
Direct Drives & Systems
Chapter E: Appendixes ETEL Doc. - Operation & Software Manual # DSC2P 903 / Ver. F / 3/6/05
18.4 Warnings for DSCDM
M66 Displayed message Description
1 W I2T WARNING This warning occurs when M67 is greater than K85/2
2 W OVER TEMPERAT This warning occurs when the temperature of the controller is greater than 65°C
3 W UNDER VOLTAGE Power voltage too low
5 W ENCODE AMPLITU This warning occurs when the amplitude of the analog encoder signals is too small (2x the error)
6 TRACKING WARNING This warning occurs when the tracking error is greater than K30/2
8 W DIGIT. HALL Wrong value coming from the digital Hall sensor
9 WuCONTRO LSYNCHRO Loss of synchronization between the TEB signal and the controller interrupt
