ETEL Doc. - Operation & Software Manual # DSC2P 903 / Ver. F / 3/6/05 Chapter C: System functions
Operation & Software Manual
Direct Drives & Systems 179
Remark: For the DSCDP and DSCDL, if parameter K150, K151 or K158 is modified, the SAV command
must be executed on both axes.
These 3 registers allow the user to define the 'non-rectified source signal'.
It is possible to modify the offset and the amplitude of the source register signal with the MOF and MAM
commands both the alias of the parameters K154 and K155.
Remark: For the DSCDP and DSCDL, if parameter K156 or/and K157 is modified, the SAV command must
be executed on both axes.
The MAM alias use the same syntax than parameter K155. Refer to §6.3
for more information
about the syntax and the possible operators.
The output voltage of the analog output is included between +20V and –20V between XAOUT+ and XAOUT-:
+20V corresponds to -8192 increments and -20V to 8191 increments.
Here is the formula giving the rectified source register signal value from the non-rectified value:
From this point, the 'source register' mode is identical to the 'direct' mode described in the previous chapter.
The digital analog converter (DAC) may induce a small offset and amplitude error. These errors can be
removed with the DAO (DAc Offset) and DAA (DAc Amplitude) commands.
K Alias Name <p1> Comment
K150 MST:[depth].<axis>=<p1>
Source
register
type
0
1
2
3
Disables the real-time monitoring mode.
The source register is user variable X.
The source register is a parameter K.
The source register is a monitoring M.
The 4 depths of the parameter correspond to the 4 analog outputs.
K151 MSN:[depth].<axis>=<p1>
Register
index
0 - 255
Indicates the source register number. The 4 depths of the parameter correspond
to the 4 analog outputs.
K158 ASE:[depth].<axis>=<p1>
Source
register
axis
0
1
Indicates that the source register is taken from the even-numbered axis (ONLY
available on DSCDP and DSCDL).
Indicates that the source register is taken from the odd-numbered axis (ONLY
available on DSCDP and DSCDL).
The 4 depths of the parameter correspond to the 4 analog outputs.
K Alias Name <p1> Comment
K154 MOF:[depth].<axis>=<p1>
Source
register
offset
- 2
31
to
+2
31
-1
Modifies the offset of the signal sent to the digital/analog converter. The 4 depths
of the parameter correspond to the 4 analog outputs.
K155 MAM
Source
register
gain
-
Modifies the amplitude of the signal sent to the digital/analog converter. The 4
depths of the parameter correspond to the 4 analog outputs.
K Alias Name <p1> Comment
K156 DAO:[depth].<axis>=<p1>
Analog
output
offset
-32768
to
+32767
Modifies the offset of the signal sent to the analog outputs (XAOUT1 to
XAOUT4). The 4 depths of the parameter correspond to the 4 analog outputs.
K157 DAA:[depth].<axis>=<p1>
Analog
output
amplitude
-32768
to
+32767
Modifies the amplitude of the signal sent to the analog outputs (XAOUT1 to
XAOUT4). The 4 depths of the parameter correspond to the 4 analog outputs.
Rectified source signal (=K173 =XAOUT) (Non-rectified source signal K154)
K155
2
24
--------------
⋅–=
