Etel DSC Series User Manual

Operation & Software Manual
38
Direct Drives & Systems
Chapter B: System setup & tuning ETEL Doc. - Operation & Software Manual # DSC2P 903 / Ver. F / 3/6/05
Example with a DSC2P:
Warning: Risk of electrical shock! High voltage may be present on the motor connector. Turn off the
power, (or 2min for the DSCDM) and before touching them, check with a voltmeter that no
residual voltage remains on these connectors!
ENCODER
MOTOR
Mains
220 V / 50-60 Hz
(Line & Neutral)
PC with ETEL's
DSMAX or DSTEB
board mounted
inside and
ETEL Tools
software installed
Power input
Auxiliary input
TEB communication
P E
Always connect the
Protective Earth!
