EVS Multicam Version 10.01 – Operating Manual
EVS Broadcast Equipment SA – July 2009
Issue
10.01.F
25
PGMSPD/VARMAX
Pressing PgmSpd once enables the Program Speed mode and highlights this
function on the LCD. Pressing the key once more enables the Var Max mode
and highlights this function on the LCD. The PLAY key is flashing red while
either of these modes is enabled.
• Program Speed mode: In this mode, only two speed values are
available from the lever: 0% when the lever is in the lower position, or
the speed defined in the setup (p.6.1 F3) for any other position of the
lever.
• Var Max mode: the speed range defined by the lever is limited between
0% and the speed value defined in the setup (p.6.1 F3).
SW TO IN
When this function is enabled (highlighted), a camera change will cause a
jump to the corresponding IN point if existing. It will switch in Sync if no IN
point exists for the current element, or if SW to IN is OFF.
PREF
Selecting this function enables the Preference mode.
AUD.MET.
This option enables/disables the display of audio meters for all channels
using the OSD of the output monitors.
In 16-audio configurations, the audio meters in live, clip, playlist and
timeline modes are displayed on line 8 and 9 of the OSD as follows:
Audio level Display
Level 0
