The EPICenter Third-party Device Integration Framework
EPICenter Concepts and Solutions Guide
199
The following are examples of the 3Com_SuperstackerII_1100.xml file and its parent, 3Com.xml.
The
3Com.xml file:
<?xml version="1.0" encoding="utf-8" ?>
<deviceType name="3Com"
version="1"
parent="3rd Party">
<identity>
<sysObjectID protocol="SNMP">43</sysObjectID>
</identity>
<attributes>
<vendor>3Com</vendor>
<imageIconsFileName>3comicons.gif</imageIconsFileName>
<CLI.LOGIN_PROMPT> login: </CLI.LOGIN_PROMPT>
<CLI.PASSWORD_PROMPT> password: </CLI.PASSWORD_PROMPT>
<CLI.SHELL_PROMPT> [#>$] </CLI.SHELL_PROMPT>
<CLI.MORE_PROMPT> Press|to continue or|to quit: </CLI.MORE_PROMPT>
<TELNET_MACROS> true </TELNET_MACROS>
</attributes>
</deviceType>
The 3Com_SuperstackerII_1100.xml file:
<?xml version="1.0" encoding="utf-8" ?>
<deviceType name="Super Stacker II 1100"
version="1"
parent="3Com">
<identity>
<sysObjectID protocol="SNMP">43.10.27.4.1.2.1</sysObjectID>
</identity>
<attributes>
<TELNET> true </TELNET>
<TELNET_MACROS> true </TELNET_MACROS>
</attributes>
</deviceType>
Parent The parent XML file. For an individual device model, this may be
the device type XML file (e.g. in the
3Com_SuperstackerII_1100.xml file, the parent is “3Com.xml”).
For a device type XML file, such as the 3COM.xml file, the
parent is “3rdParty.xml”.
Identity Contains the sysObjectId tag
SysobjectID The OID value of the device, or the enterprise OID (if a device
type)
Protocol Use SNMP as the default value
Attributes This contains the properties that define the features and
capabilities of the 3rd party device, such as enabling Telnet.
These are described later in this section.
ImageIconsFilename Provides the name of the image that is displayed in the
Component Tree for the device. This image must be present in
the dpsimages.zip file found in the extreme.war/gifs directory.
Vendor Device vendor name.
Table 8: Attributes Used in an ATL File
TAG Attribute Value
