The VlanMgr Utility
EPICenter Concepts and Solutions Guide
255
TransferMgr -host snoopy -port 81 -user master -password king -upload -a -dip
10.20.30.40
Assuming the default location for the TFTP root directory, and assuming that this command was
executed on July 24, 2001 at 10:02 AM, this will place the device configuration information in the file
\Program Files\Extreme Networks\EPICenter
6.0\user.war\tftp\configs\2001\07\24\10_20_30_40_1002.txt
.
● To download version 6.1.8 b11 of the ExtremeWare to an i-series device, enter the following
command:
TransferMgr -user admin -software v618b11.xtr -dip 10.20.30.40
The VlanMgr Utility
The VLAN Manager utility (VlanMgr) allows you to create and delete VLANs. These commands
configure the VLANs on the specified switches as well as adding the VLAN information to the
EPICenter database.
Using the VlanMgr Command
The VlanMgr utility is located in the EPICenter bin directory, <EPICenter_install_dir>/client/bin.
By default this is
\Program Files\Extreme Networks\EPICenter 6.0\client\bin in Windows, or /
opt/ExtremeNetworks/EPICenter6.0/client/bin
in a UNIX environment.
This command includes options for specifying EPICenter server access information, the operation to be
performed (create, modify or delete), the name of the VLAN, and the devices in the VLAN with their
configuration options.
The syntax of the command is as follows:
VlanMgr -user <EPICenter username> -create <VLAN name> -dip
<IP address> <other options> {-dip <IP address> <other options>} ...
VlanMgr -user <EPICenter username> -modify <VLAN name> -dip
<IP address> <other options> {-dip <IP address> <other options>} ...
VlanMgr -user <EPICenter username> -delete <VLAN name>
The EPICenter user name and one of the main options (-create, -modify, or -delete) are required.
The
-dip option is required for a create or modify command. Other options are optional.
