The EPICenter Third-party Device Integration Framework
EPICenter Concepts and Solutions Guide
201
The dpsimages.zip File
The dpsimages.zip file contains the images used in the Component Tree that appears in places such as
the Inventory Manager.
If you are adding a completely new device or device type with its own unique image, you must add
that image to this file.
The image itself can be the same as the MapView.gif image you added into the OID folder (see “The
OID folder” on page 200) but it must be named to match the name specified in the
imageIconsFileName tag in the XML file for the device or device type (see Table 8, “Attributes Used in
an ATL File” on page 198.
For example, the dpsimages.zip file included the file
3comicons.gif, which matches the name specified
in the
3Com.xml file:
<imageIconsFileName>3comicons.gif</imageIconsFileName>
If individual devices do not require unique icons, this can be specified in the parent XML file (for the
device type) and can be left out of the XML files for individual devices of that type.
Telnet Integration
EPICenter’s 3rd party integration framework can be used to provide additional features within the
Telnet applet, including the use of Telnet macros. Telnet integration can enable the following:
● Auto-login when a user (with the appropriate role/permissions) connects to the device from the
EPICenter Interactive Telnet application
● Support for execution of Telnet macros on the device, both from within the Telnet Macro Player, and
from the right-click Telnet Macro menu.
Telnet integration involves adding some additional tags to the ATL XML file for the device or device
type. The following tags may be used to specify Telnet features:
Table 9: Tags used for Telnet integration
TAG Value Comments
TELNET_MACROS TRUE or FALSE If the value is TRUE, users will be able to execute
Telnet macros. If the value is false, telnet
macros are not supported, and users are so
informed if they try to execute a macro on the
device. This tag is required for Telnet support.
CLI.LOGIN_PROMPT A value (string) to be
displayed as the prompt
during login to the device.
If the device normally displays a specific login
prompt, you can enter it here to provide the same
interface when logging in from EPICenter. This
tag is required if the device supports Telnet.
CLI.PASSWORD_PROMPT A value (string) to be
displayed as the password
prompt during login to the
device.
Similar to the login prompt; you can enter the
same prompt used by the device. This tag is
optional.
CLI.SHELL_PROMPT Provide the pattern that
matches the CLI prompt, for
example: summit450#
Specify the format of the device CLI prompt. You
can specify multiple patterns, such as
\S[ ][#>] [Test] [EPICenter] $
This tag is required for Telnet support.
