DTP CrossPoint 84 Series Matrix Switchers • DSP SIS Commands 145
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Group Masters (continued)
View a group mute
control
EDX6#GRPM} X6@]
Set soft limits
ELX6#*X6^
upper
*X6^
lower
GRPM} Set the groups soft limits to X6^ and X6^.
GrpmL
X6#*X6^*X6^]
Example:
EL2*+60*-60GRPM}
GrpmL2*60*–60]
Set the upper soft limit for the group 2
fader to +6.0dB and the lower limit to
-6.0dB.
View soft limits
ELX6#GRPM
}
GrpmLX6#*X6^*X6^]
In verbose modes 0 and 1, the response
is simplified to
X6^*X6^].
View group type
EPX6#GRPM} GrpmPX6#*X6&] Show the group type (X6&) for group X6#.
In verbose modes 0 and 1, the response
is simplified to
X6&].
View group members
EOX6#GRPM} X6) is the control or mix-point. In verbose
modes 0 and 1, the response is simplified
to
X6)1*X6)2*...*X6)16].
GrpmO
X6#*X6)
1
*X6)
2
*...*X6)
16
]
KEY: X6@ = Mute and phantom power status
X6# = Group master group number 01 – 32
X6^ = Group fader soft limit dB value, in 0.1dB increments.
X6^ must be within the range for the gain block grouped in X6#.
X6& = Group type 6= gain 12 = mute
