TP and Expansion ports
The TP input and output ports are compatible with Extron XTP DTP 24 SF/UTP cables, as
well as CAT 5e, 6, 6a, and 7 shielded twisted pair (F/UTP, SF/UTP, and S/FTP) cable. The
Expansion port requires CAT 5e, 6, 6a, or 7 shielded twisted pair cable.
For the TP ports only —
ATTENTION:
• Do not connect these ports to a computer data or telecommunications network.
• Ne connectez pas ces port à des données informatiques ou à un réseau de
télécommunications.
•
Do not use Extr
on UTP23SF-4 Enhanced Skew-Free AV UTP cable or
STP201 cable to link the matrix switcher to Extron DTP or XTP products or
HDBaseT-enabled devices.
•
N’utilisez pas le câble A
V Skew-Free UTP version améliorée UTP23SF d’Extron ou
le câble STP201 pour relier la grille de commutation avec des produits XTP ou DTP
d’Extron, ou des appareils équipés HDBaseT.
•
T
o ensure FCC Class A and CE compliance, STP cables and STP connectors are
required.
•
Afin de s’assur
er de la compatibilité entre FCC ClasseA et CE, les câbles STP et
les connecteurs STP sont nécessaires.
Extron recommends using the following practices to achieve full transmission distances up
to 330 feet (100 m) and reduce transmission errors.
•
Use the following Extr
on XTP DTP 24 cables and connectors for the best performance:
•
XTP DTP 24/1000 Non-Plenum 1000’ (305 m) spool
• XTP DTP 24P/1000 Plenum 1000’ (305 m) spool
• XTP DTP 24 Plug Package of 10
• If you not using XTP DTP 24 cable, Extr
on recommends, at a minimum, using 24 AWG,
solid conductor, STP cable with a minimum bandwidth of 400 MHz.
•
T
erminate cables with shielded connectors to the TIA/EIA T 568 B standard only (see
figure10 on page17).
•
Limit the use of mor
e than two pass-through points, which may include patch points,
punch down connectors, couplers, and power injectors. If these pass-through points
are required, use CAT 6 or 6a shielded couplers and punch down connectors.
NOTE: When using cable in bundles or conduits, consider the following:
• Do not exceed 40% fill capacity in conduits.
• Do not comb the cable for the first 65 feet (20 meters), where cables are
straightened, aligned, and secured in tight bundles.
• Loosely place cables and limit the use of tie wraps or hook and loop fasteners.
• Separate twisted pair cables from AC power cables.
