DTP CrossPoint 84 Series Matrix Switchers • Programming Guide 57
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
X#
Source or value
X#
Source or value
X#
Source or value
X#
Source or value
Assigned output values
01
Output 1
02
Output 2
03
Output 3
04
Output 4
DVI – PC values
05
1024x768 @ 50 Hz
13
1280x1024 @ 50 Hz
21
1440x900 @ 50 Hz
29
1920x1080 @ 50 Hz
06
1024x768 @ 60 Hz
14
1280x1024 @ 60 Hz
22
1440x900 @ 60 Hz
30
1920x1080 @ 60 Hz
07
1280x720 @ 50 Hz
15
1360x768 @ 50 Hz
23
1600x900 @ 50 Hz
31
1920x1200 @ 50 Hz
08
1280x720 @ 60 Hz
16
1360x768 @ 60 Hz
24
1600x900 @ 60 Hz
32
1920x1200 @ 60 Hz
09
1280x768 @ 50 Hz
17
1366x768 @ 50 Hz
25
1600x1200 @ 50 Hz
33
2048x1080 @ 50 Hz
10
1280x768 @ 60 Hz
18
1366x768 @ 60 Hz
26
1600x1200 @ 60 Hz
34
2048x1080 @ 60 Hz
11
1280x800 @ 50 Hz
19
1400x1050 @ 50 Hz
27
1680x1050 @ 50 Hz
12
1280x800 @ 60 Hz
20
1400x1050 @ 60 Hz
28
1680x1050 @ 60 Hz
HDMI – PC values, 2-channel Audio
35
1024x768 @ 50 Hz
42
1280x1024 @ 60 Hz
49
1440x900 @ 50 Hz
56
1680x1050 @ 60 Hz
36
1024x768 @ 60 Hz
43
1360x768 @ 50 Hz
50
1440x900 @ 60 Hz
57
1920x1200 @ 50 Hz
37
1280x768 @ 50 Hz
44
1360x768 @ 60 Hz
51
1600x900 @ 50 Hz
58
1920x1200 @ 60 Hz
38
1280x768 @ 60 Hz
45
1366x768 @ 50 Hz
52
1600x900 @ 60 Hz
59
2048x1080 @ 50 Hz
39
1280x800 @ 50 Hz
46
1366x768 @ 60 Hz
53
1600x1200 @ 50 Hz
60
2048x1080 @ 60 Hz
40
1280x800 @ 60 Hz
47
1400x1050 @ 50 Hz
54
1600x1200 @ 60 Hz
41
1280x1024 @ 50 Hz
48
1400x1050 @ 60 Hz
55
1680x1050 @ 50 Hz
HDMI HDTV
61
480p @ 60 Hz
2-channel audio
65
720p @ 50 Hz
multi-channel audio
69
1080i @ 50 Hz
multi-channel audio
73
1080p @ 50 Hz
multi-channel audio
62
576p @ 50 Hz
2-channel audio
66
720p @ 60 Hz
multi-channel audio
70
1080i @ 60 Hz
multi-channel audio
74
1080p @ 60 Hz
multi-channel audio
63
720p @ 50 Hz
2-channel audio
67
1080i @ 50 Hz
2-channel audio
71
1080p @ 50 Hz
2-channel audio
64*
720p @ 60 Hz
2-channel audio
68
1080i @ 60 Hz
2-channel audio
72
1080p @ 60 Hz
2-channel audio
User – Assigned EDIDs
75
User assigned 1
77
User assigned 3
79
User assigned 5
81
User assigned 7
76
User assigned 2
78
User assigned 4
80
User assigned 6
82
User assigned 8
* Default value
Table 3. EDID Values
Assign EDID data to all
inputs
EAX#*EDID} EdidAX#] Assign an EDID value of X# to all inputs.
View EDID input
assignment
EAX!EDID} X#]
Save output EDID to
user assigned slot
ESX@*X#EDID} EdidSX@*X#] Save the output 1 EDID to location X#.
Example:
ES1*75EDID} EdidS1*75]
Save the output 1 EDID to user location 1.
Import EDID to user slot
EIX#,X$EDID} EdidIX#]
Export EDID
EEX#,X$EDID} EdidEX#]
KEY: X! = Input number 01 – 08
X@ = Output number 01 – 04
X# = EDID value (resolution and rate) See table3.
X$ = EDID filename nnnnn.bin. Can include a full path name. File carries 128 or 256 bytes of data.
