DTP CrossPoint 84 Series Matrix Switchers • Programming Guide 59
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
HDMI output settings
Set output HDCP mode
to auto
ESX@*0HDCP} HdcpSX@*0] Set output X@ HDCP to auto.
Set output HDCP mode
to follow (DVI)
ESX@*2HDCP} HdcpSX@*2] Set output X@ HDCP to auto (mode 2).
Set output HDCP mode
to on
ESX@*1HDCP} HdcpSX@*1]
Set output X@ HDCP to always encrypted.
Set output HDCP mode
to on (DVI)
ESX@*3HDCP} HdcpSX@*3] Set output X@ HDCP to on (always
encrypted) (mode 3).
View output HDCP
mode
ESX@HDCP} X1)]
HDCP Status
View input HDCP status
EIX!HDCP} X1!]
HdcpIX!*X1!] for verbose mode 2 and 3.
View HDCP status of all
inputs
EIHDCP} X1!
1
X1!
2
X1!
3
... X1!
8
]
View output HDCP
status
EOX@HDCP} X1@]
HdcpOX@*X1@] for verbose mode 2 and 3.
View HDCP status of all
outputs
EOHDCP} X1@
1
X1@
2
X1@
3
X1@
4
]
Output Format
Set output format
EX@*X1#VTPO} VtpoX@*X1#]
View output format
EX@VTPO} X1#]
Output Video Dit Depth
Set bit depth
EX@*X1$BITD} BitdX@*X1$]
View bit depth
EX@BITD} X1$]
View Ties and Mutes
Read video output tie
X@% X!] Video input X! is tied to output X@.
Example:
7%
02
]
input 2 video is tied to output 7.
Read audio output tie
X@$ X!] Audio input X! is tied to output X@.
Example:
3$
06
]
Input 6 audio is tied to output 3.
View video output
mutes
EVM} MutX1%
1
X1%
2
X1%
3
X1%
4
] Each X1% is the video mute status of an
output: left = output 1, right = output 4).
NOTE: The “Mut” portion of the response appears only when the switcher is in Verbose mode 2 or 3.
KEY: X! = Input number 01 – 08
X@ = Output number 01 – 04
X1! = HDCP status (for inputs) 0 = No source device connected 2 = Source connected is not HDCP-compliant
1 = Source connected is HDCP-compliant
X1@ = HDCP status (for outputs) 0 = No monitor connected
1 = Monitor connected, does not support HDCP
2 = Monitor connected, supports HDCP ,the video signal is not encrypted
3 = Monitor connected, supports HDCP, the video signal is encrypted
X1# = Video format 0 = Auto (HDMI RGB Full to CEA sink or DVI to non-CEA sink)
1 = DVI (RGB 444, no audio, no InfoFrames)
2 = HDMI RGB Full (RGB 444, 000 - 255 audio, InfoFrames)
3 = HDMI RGB Limited (RGB 444, 016 - 255 audio, InfoFrames)
4 = HDMI YUV Full (RGB 444, 000 - 255 audio, InfoFrames)
5 = HDMI YUV Limited (RGB 444, 016 - 255 audio, InfoFrames)
6 = HDMI YUV Full (RGB 422, 000 - 255 audio, InfoFrames)
7 = HDMI YUV Limited (RGB 422, 016 - 255 audio, InfoFrames)
X1$ = Output video bit depth 0 = Auto (default) 1 = 8-bit
X1% = Video mute status 0 = No mutes 1 = Video mute 2 = Video and sync
