DTP CrossPoint 84 Series Matrix Switchers • Programming Guide 60
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Input Sync Detection
View all input
connections
0LS
Frq00•
X1^
1
X1^
2
... X1^
8
] Each X1^ is the connection status of an
input, starting from input 1.
NOTE: The “Frq00•” portion of the response appears only when the switcher is in Verbose mode 2 or 3.
Example:
0LS
Input:
Response Status:
No input detected
Sync detected
1 2345
6
7 8
0 0 0 1 1 1 0 1
DTP/HDBaseT/XTP Switch Positions
View input switch
position
EIX1&HDBT} X1*] HdbtIX1&*X1*] for verbose mode 2 and
3.
View output switch
position
EOX1(HDBT} X1*] HdbtOX1(*X1*] for verbose mode 2 and
3.
Names
NOTE: The HTML language reserves certain characters for specific functions (see Special Characters on page69).
Write input name
EX!,X2)NI} NmiX!,X2)]
Example:
E1,Podium camNI} Nmi01,Podium cam]
Name input 1 “Podium cam”.
Read input name
EX!NI} X2)]
Write output name
EX@,X2)NO} NmoX@,X2)]
Example:
E1,Main PJ1NO} Nmo01,Main PJ1]
Name output 1 “Main PJ1”.
Read output name
EX@NO} X2)]
Write EDID name
EEX#*X2)UNAM} UnamEX#*X2)]
NOTE: For the Write, Clear, and Read EDID Name commands, X# is valid only in the range of 75 through 82 (User EDID slots 1 through 8).
Example:
EE75*Slot 1UNAM} UnamE75*Slot 1]
Name EDID location 75 “Slot 1“.
Clear EDID name
EEX#*•UNAM} UnamE75*USER•n]
n = 1 through 8.
Read EDID name
EEX#UNAM} X2)]
Write scaler preset
name
E2*X2#,X2)PNAM} Pnam2*X2#,X2)]
Example:
E2*5,preset
1PNAM
}
Pnam2*005,preset 1]
Name scaler preset 5 “preset 1”.
Read scaler preset
name
E2*X2#PNAM] X2)]
KEY: X! = Input number 01 – 08
X@ = Output number 01 – 04
X# = EDID value (resolution and rate) See table3 on page57
X1^ = Input signal status 0 = No signal detected 1 = Sync detected
X1& = TP and insertion input number 07 or 08
X1* = Switch position 0 = DTP 1 = HDBT (output only) 2 = XTP
X1( = TP (scaled) and insertion output number 03 or 04
X2) = Name Up to 12 upper- and lower-case alphanumeric characters and _ / and spaces
X2! = Preset number 01 – 32
X2@ = Lock mode 0 = Mode 0 1 = Mode 1 2 = Mode 2 (default)
X2# = Scaler preset 001 – 128
