DTP CrossPoint 84 Series Matrix Switchers • Programming Guide 62
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Information Requests (continued)
Query controller
firmware version
(verbose)
0Q
X2$-X2%-X2%]
Detailed status of the controller firmware
and any firmware upgrade. The active
firmware is marked by an asterisk (*). A
caret (^) indicates a bad checksum or an
invalid load. ?.?? indicates that firmware is
not loaded.
Response description: Ethernet protocol rmware version-controller rmware version-updated rmware version
Example:
0q
See below
Ether
net protocol
firmware
Description
DTP CrossPoint firmware version Updated firmware version
* indicates the version running Upload date and time
1.23-1.00(1.06LX-DTPCP84 -Tue, 08 Apr 2014 00:00:00 UTC)-1.00*(1.06LX-DTPCP84 -Mon, 21 Apr 2014 16:39:21 UTC)
Request system status
S
Sts00*
X2^•X2&•X2*•X2*]
NOTE: The “Sts00*” portion of the response appears only when the switcher is in Verbose mode 2 or 3.
Response description: Power supply•Temperature Celsius•Fan 1 RPM•Fan 2 RPM]
Example:
S
Power supply at 12.25V
Temperature is 35.0 °C
Fan 2 rotating at 2004 RPM
12.250
•35.000•1976•2004
KEY: X2$ = Firmware version number to second decimal place (x.xx)
X2% = Verbose firmware version-description-upload date and time.
X2^ = Voltage Positive or negative voltage and magnitude
X2& = Internal temperature Degrees Celsius
X2* = Fan speed RPM
View and Erase File Directory
NOTE: The response to the View File Directory command differs, depending on whether the command is sent via an RS-232 or Telnet connection or
sent via a Web browser connection.
View file directory
RS-232 port and Telnet
EDF}
See below: List user-supplied files.
lename1•date/time•length
]
lename2•date/time•length
]
• •
• •
lenamen•date/time•length]
# of•Bytes•Left
]]
View file directory
Web browser
EDF}
See below: List user-supplied files.
Var
•le•=•new•array•();
File•[1]•=•‘lename1,date1,lesize1‘;
File•[2]•=•‘lename3,date3,lesize3‘;
• •
• •
File•[n]•=•‘lenamen,daten,lesizen‘;
File•[n+1]•=•# of•Bytes•Left
Erase user-supplied
web page/files
ElenameEF} Del•lename]
