DTP CrossPoint 84 Series Matrix Switchers • Programming Guide 65
Command Function
SIS Command
(Host to Unit)
Response
(Unit to Host)
Additional description
Save and Recall Scaler Presets
NOTE: If you try to recall a scaler preset that is not saved, the matrix switcher responds with the error code E13.
Save a scaler preset
2*
X1(*X2#, 2SprX1(*X2#]
Command character is a comma.
Recall a scaler preset
2*
X1(*X2#. 2RprX1(*X2#]
Command character is a period.
Example:
2*3*5.
2Rpr3*005
]
Recall preset 5, which becomes the
current configuration.
Erase a scaler preset
EX2*X2#PRST} PrstX2*X2#]
Show scaler preset
availabilities
51#
PreI
X%
1
X%
2
X%
3
... X%
128
] Each X% is the availability status of a
scaler preset, starting from preset 1.
NOTE: The “PreI” portion of the response appears only when the switcher is in Verbose mode 2 or 3.
Auto Memories
Enable auto memories
EX1(*1AMEM} AmemX1(*1]
Set auto memories on. Previous settings
for the incoming signal are recalled.
Disable auto memories
EX1(*0AMEM} AmemX1(*0]
Set auto memories off.
Show auto memory
status
EX1(AMEM} X%]
Default = 0.
Test Pattern
Enable a test pattern
EX1(*X3$TEST} TestX1(*X3$]
Disable test patterns
EX1(*0TEST} TestX1(*0]
View test pattern
selection
EX1(TEST} X3$]
Screen Saver Timeout and Status
Set screen saver to go
black immediately
ETX1(*0SSAV} SsavTX1(*000]
Disable sync whenever no input video is
preset.
Set screen saver
timeout duration
ETX1(*X3%SSAV} SsavTX1(*X3%] Blank output X1( after X3% seconds.
Example:
ET3*300SSAV} SsavT3*300]
Blank output 3 after 300 seconds
(5 minutes).
Set screen saver to
never go black
ETX1(*501SSAV} SsavTX1(*501] Do not blank output X1(.
View screen saver
timeout duration
ETX1(SSAV} X3%]
View screen saver
status
ESX1(SSAV} X3^]
KEY: X% = Available or enable 0 = Not available or disable 1 = Available or enable
X1( = TP (scaled) and insertion output number 03 or 04
X2# = Scaler preset 001 – 128
X3$ = Test pattern 00 = Disable (default) 02 = Alternating pixels 04 = Color bars 06 = Blue mode
01 = Crop 03 = Crosshatch 05 = Grayscale
X3% = Duration 0 = Output sync instantly disabled when no active video input is selected
001 through 500 (seconds) 501 = Output sync never times out (default)
X3^ = Screen saver status 0 = Active input detected, timer is not running
1 = No active input, timer is running, output sync is still active
2 = No active input, timer is expired, output sync is disabled see table4 on page66
X3* = Captive screw or UART 0 = Captive screw RS-232 insert 1 = Ethernet RS-232 insert (UART) (default)
