RESTRICTED USE ONLY Fargo Electronics, Inc.
DTC500 Series Card Printer/Encoders User Guide (Rev. 5.0)
147
Attaching the Card Lamination Module (continued)
Step Procedure
5 a. Connect the lamination module's Power Cable to the Printer's Power Port.
(Note: both are labeled with a red Power label.)
b. Push firmly to ensure both are securely connected. (Note: The port and
cable are keyed for one way installation.)
Continued on the next page
