Pro-LX Laminating Card Printer/Encoder User Guide (Rev. 5.0) 113
Using Image Position controls
Use the Image Position controls to adjust the position of the overall print area to be
precisely centered on a card.
Step Procedure
1
Click on the Vertical and Horizontal adjustment arrows to adjust the Image
Position values.
 When adjusting these values, keep in mind that cards always remain in the
same position while moving through the Printer, regardless of image
orientation.
 To illustrate this, the card illustration shown in the Image Position box will flip
and rotate according to the Portrait, Landscape or Rotate 180 Degrees
selection.
 The outline around the illustration will always remain in the same Landscape
orientation.
