Resolving the DRAM Memory Error
Symptom: A DRAM Memory Error is displayed on the LCD display.
Step Procedure
1 Reboot the Printer.
2 If the problem persists, remove the rear cover and ensure that the SIMM
(080016) is seated properly.
3 If the memory module is not seated properly, remove the board and reinstall.
4 If the installation appears correct and the error persists, the SIMM (080016) on
the Main Print Board will need to be replaced.
Sensor Testing
Step Procedure
1 Check the voltage to determine if a Sensor is working.
2 a. Test the voltage of each Sensor using ground (GRD = Chassis) to the
correct pin on each connector. See the Sensor Location and Voltages
table on the next page.
b. Block a Slot Sensor with a card.
c. Cover a Reflective Sensor with a card.
