Pro-LX Laminating Card Printer/Encoder User Guide (Rev. 5.0) 198
Reviewing the Motor Voltages (when active)
Use this table as a reference tool for Board Level Diagnostics.
Motor Location Pin VDC
Print Drive
Stepper
J22 4 5
Lamination
Drive Stepper
J24 4 5
Print Headlift J27 1 17.0
Lamination
Roller Lift
J29 4 23.00
Card Feed J28 4 20
Ribbon Drive J25 2 5
Lamination
Drive
J26 2 5
