RESTRICTED USE ONLY Fargo Electronics, Inc.
Pro-LX Laminating Card Printer/Encoder User Guide (Rev. 5.0) 197
Reviewing the Sensor Location and Voltages
Use this table as a reference tool for Board Level Diagnostics.
Sensor Location
Pin Low Range VDC High Range VDC
Print Ribbon ID J33 3 Present .02 Not present .70
Lam Ribbon ID J2 on
Encoder
Board
3 Present .02 Not present .70
Print Headlift J3 3 Unblocked 2.2 Blocked 5
Lam Roller Lift J4 3 Unblocked 2.2 Blocked 5
Print Cover Sensor J11 2 Unblocked 2.2 Blocked 5
Lam Cover Sensor J12 2 Unblocked 2.2 Blocked 5
Print Ribbon Encoder
Sensor
J13 4 Unblocked .17 -.9 Blocked 5
Lamination Ribbon
Encoder Sensor
J3 on
Encoder
Board
4 Unblocked .17 -.9 Blocked 5
Card Detection
Sensor
J4 4 Unblocked .17 -.9 Blocked 5
Print TOF Sensor J6 4 Unblocked .17 -.9 Blocked 5
Lamination TOF
Sensor
J7 4 Unblocked .17 -.9 Blocked 5
Flipper Home Sensor J8 4 Covered .17 -.9 Uncovered 3.8-3.5
Encoder TOF Sensor J31 4 Covered .17 -.9 Uncovered 3.8-3.5
