RESTRICTED USE ONLY Fargo Electronics, Inc.
Pro-LX Laminating Card Printer/Encoder User Guide (Rev. 5.0) 195
Section 6: Board Level Diagnostics
The purpose of this section to provide the User with specific Board Level Diagnostic
procedures for Board Errors and Sensor Testing for the Pro-LX Card Printer.
Board Errors
Resolving the EE Memory Error
Symptom: An EE Memory Error is displayed on the LCD display.
Step Procedure
1 Reboot the Printer.
2 If the problem persists, the Main Print Board will need to be replaced. See
Replacing the Main Board procedure in Section 5, page Error! Bookmark not
defined..
3 As an alternative to replacing the Main Print Board, the chip U16 (080196) may
be replaced. (Note: Fargo recommends that only a qualified electronics
technician perform this procedure.)
Resolving the EE Checksum Error
Symptom: An EE Checksum Error is displayed on the LCD display.
Step Procedure
1 Reboot the Printer.
2 If the problem persists, the Main Print Board will need to be replaced. See
Replacing the Main Board procedure in Section 5, page Error! Bookmark not
defined..
3 As an alternative to replacing the Main Print Board, the chip U16 (080196) may
be replaced. (Note: Fargo recommends that only a qualified electronics
technician perform this procedure.)
