Reviewing the Printer Timing
Interval Description Minimum
Value
Typical Value
Tdsu Data setup time 0.5 µs
Tstr
_____
Data strobe width
1 µs
Tack ______
Acknlg pulse
width
3.75 µs
Tdh Data hold time 0.5 µs
Tsb
_____
Busy delay
time from
data strobe
0.5 µs (max.)
