Pro-LX Laminating Card Printer/Encoder User Guide (Rev. 5.0) 130
Reviewing ISO Track Locations
Review the magnetic encoding module, which encodes onto Tracks in accordance with an
ISO 7811-2 Magnetic Stripe. (Note: Refer to the diagram (below) for Track locations.)
TRACK1 0.110"
TRACK2 0.110"
TRACK3 0.110"
0.130"
0.140"
0.223" 0.353" 0.493"
