Pro-LX Laminating Card Printer/Encoder User Guide (Rev. 5.0) 61
Resolving the Skipping Ribbon Panel issues (continued)
Step Procedure
2 Adjust the Ribbon Clutch
a. Remove the back cover.
b. Use a 7/16
th
wrench to tighten the nut on the end of the encoder wheel
by a ½ - turn.
3 Test the Encoder Sensor.
a. Remove the back cover.
b. Using a Digital Voltmeter, connect the negative lead to ground.
c. Connect the positive lead to Pin 4 of J13.
 If blocked, the voltage should read 4.9 to 5.5 volts DC.
 If unblocked, the Sensor should read 0.15 to 0.18 volts DC.
