INSTALLATION ST80/ST80L Flow Meter
16 Fluid Components International LLC
Figure 12 – Remote Installation, Optional Stainless Steel Bracket on 2" Pipe
C01247-2-1
2x M4 SCREWS
(FCI PROVIDED)
2x ¼"-20
U BOLTS, SST
4x ¼" HEX NUT
2" PIPE
ST100A SERIES
TRANSMITTER
(4.25)
(9.25)
