FCI ST80 Series User Manual

ST80/ST80L Flow Meter APPENDIX B – ADDITIONAL INFORMATION
Fluid Components International LLC 129
HMI Menu Outline
● Boot Screen
● Process Data Screen
□ Percentage of Flow
□ Flowrate
□ Totalizer
□ Temperature
□ Pressure
□ Group
□ Group Name
● Service
○ Select Group
■ Password
◘ 1: [group name]
◘ 2: [group name]
◘ 3: [group name]
◘ 4: [group name]
◘ 5: [group name]
○ Alarm Ack
■ [alarm ACK list]
○ Diagnostics
■ Show Faults
◘ [fault codes list]
■ Self Test
◘ FE 1 IDR
– Password
■ Raw Signal
◘ FE1
F1 Raw Signal
– RefR: [value]
– dR: [value]
– dTdR: [value]
– Temp: [value]
– Flow: [value]
○ Set-up
■ Instrument
◘ Group ‘X’ [current active group]
– Flow: [eng units]
– Temp: [Deg F or Deg C]
– Pres: N/A
– Name: [group name]
– Restore
– Pipe: [Round or Rect.]
– W: [dimension, inch]
– H: [dimension, inch]
■ Display
◘ Orientation
[select display orientation]
◘ Contrast
[select display contrast]
■ Language
◘ English
○ SDcard N/A
■ Remove
■ Inserted
○ Device
■ Serial No: [ser. no]
■ Sales Ord No: [sales ord. no.]
■ Software version [ver. no.]
○ FE Control
■ FE1: [Online or Offline]
◘ Password
FE1 Control
– Online
– Offline
