Settings for measurement
21
MMS
®
Inspection DPM High
5.1 Creating a new batch
Each batch contains settings for the measurement procedure.
The batch settings selection is based on the requirements in a directive/stan-
dard or according to customer specifications.
You can create a batch in two ways:
Create a new batch with factory presettings that you can change as re-
quired, see page 21
Create a new batch by copying an existing batch, see page 22
5.1.1 Creating a new batch
Use the New function to create a new batch with the presettings for unit of mea-
surement and display resolution. You can select these presettings in the Gage
Settings menu, see pages 75.
Navigation
: Selects - parameter/value
: Confirms - selection/setting
: Exits - page/menu
To create a new batch
► Main menu ( ) > Batches > OK > New > OK
This completes the creation process for a new batch. The Measurement view of
the newly created batch appears in the display.
What you can do next
Measure, see page 28
Make settings for the measurement (e.g. set specification limits, enable
alarm function, interval time for log function), for an overview, see
page 20.
Rename this batch, see page 61.
