Settings for measurement
24 MMS
®
Inspection DPM High
5.3 Limit monitoring
You can monitor and record during the measurement whether the climatic val-
ues are within specified limits. The reading will displayed in red in case of limit
violation.
Activate specification limit monitoring, set limits, see page 24
Deactivate specification limit monitoring, see page 25
A description of the parameters can be found in the glossary, starting on
page 95
5.3.1 Activating specification limit monitoring
Before you start
The batch for which you want to make the change is open.
Navigation
: Selects – parameter/value
: Confirms – selection/settings
: Exits – page/menu
: Cancels – leave page/menu without saving changes
To set the parameters for specification limit monitoring
1. Select the climatic variable to be monitored: Main menu ( ) > Batch
Modify > OK > Tolerance Limits > OK > select climatic variable > OK.
2. Enable limit monitoring, select parameter
Both
:
Parameter Both is activated:
The specification limit(s) with the currently set value(s) appear in the
Tolerance Limits menu.
3. Set the specification limit:
Select specification limit
> OK >
set desired value
> OK
.
Repeat step 3. for the second specification limit.
The settings are now finished.
