Gage settings
70 MMS
®
Inspection DPM High
10.3 Enabling/disabling the visual signals
You can enable and disable the visual alarm signal to indicate limit violations.
Alarm function activated and function visual signals switched on: limit viola-
tions will be indicated by a red flashing signal lamp.
Navigation
: Selects – parameter/value
: Confirms – selection/setting
Enables/Disables – function
:Exits – page/menu
To enable/disable the visual signals
► Main menu ( ) > Gage Settings > OK > Indication Settings > OK >
Optical Indic. > OK
Signal LED enabled:
Signal LED disabled:
The setting is finished.
What you can do next
Set visual signal luminosity; see page 71.
Go to the Measurement view: 2x > , measure, see page 28.
