Gage settings
67
MMS
®
Inspection DPM High
10.2 Display settings
The following settings are possible:
Select display brightness mode, see page 67
Set display brightness for the modes, see page 68
Activate/deactivate flip display, see page 69
10.2.1 Display brightness modes
For the display you can select between the different brightness modes Office,
Sunlight, Night and Automatic.
A description of the brightness modes can be found in the Glossary, start-
ing on page 95.
Navigation
: Selects – parameter/value
: Confirms – selection/setting
:Exits – page/menu
To select brightness mode
► Main menu ( ) > Gage Settings > OK > Display Settings > OK > Bright.
Mode > OK > select desired mode > OK
Parameter is activated:
The selection is finished.
What you can do next
Make further display settings: 1x .
Adjust properties for the brightness modes; see page 68.
Make further gage settings: 2x .
Go to the Measurement view: 3x > , measure, see page 28.
Go to the main menu:
3x
.
