10 Measurement
10.1 Enabling the analysis PIOX S72*
2022-05-15, UMPIOX_S72xV1-9EN
100
10 Measurement
10.1 Enabling the analysis
• Select the menu item Measurement in the program branch Special functions.
• Press ENTER.
• Select the menu item Measurement modes.
• Press ENTER.
•Select On to enable the analysis. Select Off to disable it.
• Press ENTER.
• Enter the temperature for the local reference conditions (default value: 20 °C).
• Press ENTER.
Risk of explosion when using the measuring equipment in explosive atmospheres (ATEX, IECEx)
This may result in personal or material damage or dangerous situations.
→ Observe the "Safety instructions for the use in explosive atmospheres" (see document SIFLUXUS).
Risk of explosion when using the measuring equipment in explosive atmospheres (TR TS)
This may result in personal or material damage or dangerous situations.
→ Observe the "Safety instructions for the use in explosive atmospheres" (see document SIFLUXUSRU).
Warning of severe injuries from hot or cold components
Touching hot or cold components can lead to severe injuries (e.g., thermal damage).
→ Any mounting, installation or connection work has to be concluded.
→ Any work on the measuring point during the measurement is prohibited.
→ Observe the ambient conditions at the measuring point during installation.
→ Wear the required personal protective equipment.
→ Observe the applicable rules.
If the analysis is not enabled, the transmitter works as an ultrasonic flowmeter. All menu displays relating to the
analysis are faded out.
During the parameter input, all fluids stored in the transmitter are displayed. A mass flow rate measurement for a
given concentration (e.g. H
2
SO
4
of 0…80 %) is possible.
Special functions\Measurement\Measurement modes
Special functions\Measurement\Measurement modes\Enable analysis
Special functions\Measurement\Measurement modes\Reference temp.
