16.2 Configuration of a digital output as pulse output
A pulse output is an integrating output which emits a pulse when the volume or the mass of the fluid which has passed the
measuring point reaches a certain value (pulse value).
The integrated quantity is the selected physical quantity. The integration is restarted as soon as the pulse is emitted.
Before the activation, the digital output has to be configured.
• Select the menu item Options\Channel A\Outputs\Digital output.
• Press ENTER.
Assignment of a source item
•Select Pulse as source item.
• Press ENTER.
• Select a list item (here: Pulse +V):
• Press ENTER.
Tab. 16.5: Output function test – measuring range
list item switching function test value description
Status OK
(status value)
NC Status OK • binary output is energized
• measured value has to be low ohmic
Status error • binary output is de-energized
• measured value has to be high ohmic
NO Status OK • binary output is de-energized
• measured value has to be high ohmic
Status error • binary output is energized
• measured value has to be low ohmic
Idle state
(event value)
NC Passive • binary output is energized
• measured value has to be low ohmic
Active • binary output is de-energized
• measured value has to be high ohmic
NO Passive • binary output is de-energized
• measured value has to be high ohmic
Active • binary output is energized
• measured value has to be low ohmic
Options\Channel A\Outputs\Digital output
Options\Channel A\Outputs\Digital output B1\Source item\Pulse
Options\Channel A\Outputs\Digital output B1\Source item\Pulse\Pulse +V
