Flexim PIOX S72 Series User Manual

20 Advanced functions
20.4 Modification of the limit for the inner pipe diameter PIOX S72*
2022-05-15, UMPIOX_S72xV1-9EN
180
20.3.3 Information concerning snaps
• Select the menu item Snap info.
• Press ENTER.
The following information is displayed:
20.3.4 Deletion of snaps
• Select the menu item Delete snaps.
• Press ENTER.
•Select Yes or No.
• Press ENTER.
20.4 Modification of the limit for the inner pipe diameter
It is possible to modify the lower limit of the inner pipe diameter for a given transducer type.
• Select the program branch Special functions.
• Press ENTER.
•Select Pipe diameter MIN.
• Press ENTER.
It is possible to define a min. pipe diameter for all relevant transducer frequencies.
•Select Default if no customized inputs are to be made and the default values are to be used.
• Press ENTER.
•Select Customized if a min. pipe diameter is to be defined.
• Press ENTER.
• Enter the pipe diameter in mm.
• Press ENTER.
Special functions\ Snap\ Snap info
display description
Stored snaps: number of stored snaps
Snaps left: number of snaps that can still be stored
Ringbuffer: snap ringbuffer activated
Special functions\ Snap\Delete snaps
Special functions\Pipe diameter MIN
Notice!
If a transducer is used below its recommended inner pipe diameter, a measurement might be impossible.
