21 Settings
21.1 Dialogs and menus PIOX S72*
2022-05-15, UMPIOX_S72xV1-9EN
188
21 Settings
21.1 Dialogs and menus
• Select the menu item Dialogs/Menus in the program branch Special functions.
• Press ENTER.
Pipe circumference
• Select the menu item Pipe circumference.
•Select Yes if the pipe circumference is to be entered instead of the pipe diameter in the program branch Parameters.
• Press ENTER.
If Yes is selected for Pipe circumference, the outer pipe diameter will still be requested in the program branch
Parameters.
• Press to select the menu item Pipe circumference.
• Press ENTER.
The value displayed in the menu item Pipe circumference is calculated from the last displayed outer pipe diameter.
Example: 100 mm
.
π = 314.2 mm
• Enter the pipe circumference. The limits for the pipe circumference are calculated on the basis of the limits for the outer
pipe diameter.
• Press ENTER.
During the next scroll through the program branch Parameters, the outer pipe diameter that corresponds to the entered
pipe circumference will be displayed.
Example: 180 mm : π = 57.3 mm
Coating
If the pipe has a coating, the material parameters of the coating have to be entered in the program branch Parameters.
• Press ENTER until the menu item Edit coating is displayed.
•Select Yes if the pipe has a coating.
• Press ENTER.
Lining 2
If the pipe has a second lining, the material parameters of the coating have to be entered in the program branch
Parameters.
• Press ENTER until the menu item Edit Lining 2 is displayed.
•Select Yes if the pipe has 2 linings.
• Press ENTER.
Measuring point number
• Press ENTER until the menu item Measuring point no. is displayed.
•Select Number if the measuring point number should only consist of numeric characters. Select Text if the measuring
point number should only consist of alphabetic characters.
• Press ENTER.
Special functions\Dialogs/Menus
Special functions\Dialogs/Menus\Pipe circumference
Special functions\Dialogs/Menus\Edit coating
Special functions\Dialogs/Menus\Edit Lining 2
Special functions\Dialogs/Menus\Measuring point no.
