7 Mounting
PIOX S72* 7.1 Transmitter
27
UMPIOX_S72xV1-9EN, 2022-05-15
7.1 Transmitter
7.1.1 Opening and closing the housing
7.1.1.1 Opening
• Loosen the screws of the transmitter housing.
• Open the housing cover of the transmitter.
7.1.1.2 Closing
Transmitter with stainless steel housing
• Close the housing cover.
• Tighten the screws of the transmitter housing with a max. torque of 1 Nm.
Remove all protective foils before using the measuring equipment in explosive atmospheres (see document
SIFLUXUS).
Possible danger by opening the equipment at improper ambient conditions
Open the transmitter in safe ambient conditions only (e.g., air humidity < 90 %, no conductive pollution, no
explosive atmosphere). Otherwise, additional protective measures have to be taken.
Do not use objects which may damage the housing gasket to open the housing cover.
Fig. 7.1: Transmitter
1–screws
