10 Measurement
PIOX S72* 10.3 Measurement settings
107
UMPIOX_S72xV1-9EN, 2022-05-15
10.2.5 Other parameters
Extension cable
In case the transducer cable is extended (e.g., between junction box and transmitter), enter the length of the extension
cable.
• Select the menu item Extension cable in the program branch Parameters.
• Enter the length of the extension cable.
• Press ENTER.
10.3 Measurement settings
• Select the program branch Options.
•Press ENTER.
• Select the channel for which a physical quantity has to be
entered (here: Channel A)
•Press ENTER.
This display will not be indicated if the transmitter has only
one measuring channel.
• Select the menu item Measurement.
•Press ENTER.
10.3.1 Selection of the physical quantity
The available physical quantities are displayed in a list.
• Select the physical quantity.
• Press ENTER.
10.3.2 Selection of the unit of measurement
For the selected physical quantity (except sound speed), a scroll list with the available units of measurement is displayed.
• Select the unit of measurement of the physical quantity.
• Press ENTER.
Parameters\Extension cable
Options
Channel x
Measurement Units of measurement
Physical quantity Flow velocity
Unit of measurement Volumetric flow rate
Damping Mass flow rate
Dynamic damping
Physical quantity for
analysis
Error delay
see annex A
Options\Channel A
Options\Channel A\Measurement\Physical quantity
Options\...\Volumetric flow rate
Notice!
If the physical quantity or the unit of measurement is changed, the settings of the outputs have to be checked.
