5.4 Keyboard PIOX S72*
2022-05-15, UMPIOX_S72xV1-9EN
24
5.4 Keyboard
The keyboard has 15 keys, including 3 function keys: ENTER, and C.
Some keys have multiple functions. They can be used to enter data, to navigate through scroll lists as well as to execute
special functions (e.g., reset of totalizers).
Tab. 5.3: General functions
ENTER confirmation of selection or input
+ C + ENTER Reset: press these 3 keys simultaneously to correct a malfunction. The reset has the same effect as a restart
of the transmitter. Stored data are not affected.
+ C INIT: When initializing the transmitter, all settings are reset to the factory settings.
Tab. 5.4: Navigation
During the parameter input:
short press: return to the previous menu item
long press (several seconds): return to the beginning of the program branch
During the measurement:
display of scroll list: Stop measurement, Show parameters, Show measurement
scroll to the left/right through a scroll list
scroll upwards/downwards through a scroll list
ENTER confirmation of a menu item
Tab. 5.5: Input of numbers
… input of the number pictured on the key
sign for the input of negative values
decimal marker
C deletion of values
After the value has been deleted, the previous value will be displayed.
ENTER confirmation of the input
Tab. 5.6: Input of text
positioning of the cursor
"A" is displayed and capitalization is activated
"Z" is displayed and capitalization is activated
toggling between upper and lower case
selection of the previous/next character
deletion of a character and insertion of a blank
ENTER confirmation of the input
