15 Outputs (TF7-*721**-******-******a-*****-**; a = U, V, D)
15.2 Activation of a binary output as pulse output PIOX S72*
2022-05-15, UMPIOX_S72xV1-9EN
150
15.2 Activation of a binary output as pulse output
A pulse output is an integrating output which emits a pulse when the volume or the mass of the fluid which has passed the
measuring point, reaches a certain value (pulse value).
The integrated quantity is the selected physical quantity. The integration is restarted as soon as the pulse is emitted.
Before the activation, the binary output has to be configured.
• Select the list item Binary B1 in the menu item Outputs.
• Press ENTER.
• Select the list item Pulse in the menu item Source item.
• Press ENTER.
• Select a list item (here: Pulse +V).
• Press ENTER.
• Enter the pulse value.
The unit of measurement will be displayed according to the actual physical quantity.
When the counted physical quantity reaches the entered pulse value, a pulse will be transmitted.
• Press ENTER.
• Enter the pulse width.
The range of possible pulse widths depends on the specification of the instrument (e.g., counter, PLC) that is to be
connected to the output.
• Press ENTER.
Terminal assignment
The terminals for the connection of the output are displayed.
By pressing or further information is displayed.
• Press ENTER.
The activation of a binary output as pulse output is only possible for binary outputs supporting a pulse output.
Options\Channel A\Outputs\Binary B1
Options\Channel A\Outputs\Binary B1\Source item\Pulse
Options\Channel A\Outputs\Binary B1\Source item\Pulse\Pulse +V
Options\Channel A\Outputs\Binary B1\Source item\Pulse\Pulse value
Options\Channel A\Outputs\Binary B1\Source item\Pulse\Pulse width
Options\Channel A\Outputs\...\Output info
