15 Outputs (TF7-*721**-******-******a-*****-**; a = U, V, D)
PIOX S72* 15.1 Configuration of a binary output
149
UMPIOX_S72xV1-9EN, 2022-05-15
Output function test
The function of the output can now be tested.
• Connect a multimeter to the output.
•Select Yes to test the output. Select No to display the next menu item.
• Press ENTER.
•Select On to test the energized state of the output.
• Press ENTER.
The value has to be low ohmic.
•Select Off to test the de-energized state of the output.
• Press ENTER.
The value has to be high ohmic.
•Select Repeat to repeat the test, Finish to display the next menu item.
• Press ENTER.
.
•Select Yes to test the status of the output signal. Select No to display the next menu item.
• Press ENTER.
•Select Passive (idle state) or Active in case a event has been selected as source item.
• Press ENTER.
Depending on the selected switching condition, the value has to be either high or low ohmic.
•Select Repeat to repeat the test, Finish to display the next menu item.
• Press ENTER.
Options\Channel A\Outputs\...\B1 Test signal
Options\Channel A\Outputs\...\B1 Enter test value
Options\Channel A\Outputs\...\B1 Test mea. range
Options\Outputs\...\B1 Enter test value
