15 Outputs (TF7-*721**-******-******a-*****-**; a = U, V, D)
PIOX S72* 15.1 Configuration of a binary output
147
UMPIOX_S72xV1-9EN, 2022-05-15
15 Outputs (TF7-*721**-******-******a-*****-**; a = U, V, D)
If the transmitter is equipped with outputs, they have to be
configured. For the configuration of the analog output, see
section 10.3.6.
The transmitter can also be equipped with binary outputs.
A binary output switches if one of the following switching
conditions is met:
• the measured value exceeds or falls below a limit
• the measured value lays within or outside a defined range
• a measurement is not possible
• an event occurs
15.1 Configuration of a binary output
Assignment of an output
• Select the channel in the program branch Options (here: Channel A).
• Press ENTER.
This display will not be indicated if the transmitter has only one measuring channel.
• Select the list item Outputs.
• Press ENTER.
• Select the output to be assigned to the channel.
• Press ENTER.
If the channel has already been assigned to a channel, it is displayed as follows: Binary B1 (A).
•Select Yes to change the settings for an already assigned output or to assign a new output.
•Select No to cancel the assignment and to return to the previous menu item.
• Press ENTER.
Options
Channel x
Outputs
Select output
Enable output
Source item
see annex A
Options\Channel A
Options\Channel A\Outputs\Binary B1(--)
Options\Channel A\Outputs\Binary B1\B1 Enable
