19 Data transmission
19.1 Service interfaces PIOX S72*
2022-05-15, UMPIOX_S72xV1-9EN
170
19 Data transmission
The data is transmit via the service interfaces or the process interface (optional) of the transmitter.
19.1 Service interfaces
By means of the program FluxDiagReader it is possible to transmit via service interfaces (USB, LAN) data to the PC.
The following tasks can be carried out:
• read and store measured values, setup settings and snaps
• graphically display measured values
• export of data in csv format
For the operation of FluxDiagReader see the help function of this program.
19.1.1 LAN interface
In order to use the LAN interface it is important to enter the network parameters.
• Select the program branch Special functions.
• Press ENTER.
• Select the menu item Special functions\Communication\Network.
• Press ENTER.
Manual input
•Select Manual to enter the network parameter (IP address, subnet mask and standard gateway).
Default values in the transmitter:
– IP address: 192.168.0.70
– subnet mask: 255.255.255.0
– standard gateway: 192.168.0.1
Automatic addressing with DHCP
•Select Automatic to automatically identify the network parameters (IP address, subnet mask and gateway address) via
a DHCP server.
• Select the menu item Special functions\Communication\Network\Show auto config. to display the
identified network parameters.
• Press ENTER.
Special functions\Communication\Network
The entered network parameters have to accord with the network parameters of the LAN.
The network parameters can only be automatically identified if the LAN supports DCHP.
To transmit data from the PC to the transmitter, the program FluxDiag has to be used.
