Flexim PIOX S72 Series User Manual

5 Product description
PIOX S72* 5.1 Measuring system
21
UMPIOX_S72xV1-9EN, 2022-05-15
5 Product description
5.1 Measuring system
The measuring system consists of the transmitter, the temperature probe, the ultrasonic transducers and the pipe on
which the measurement is taken.
5.2 Handling concept
The transmitter is operated via the keyboard.
By pressing or the following program branches are displayed consecutively:
•Parameters
•Measurement
•Options
•Special functions
The program branch is displayed between 2 arrows ( ).
Fig. 5.1: Example of a measurement arrangement
1 – transducer
2 – temperature probe
3 – pipe
4 – transmitter
Fig. 5.2: Command panel of the transmitter
1 – LCD display (backlit)
2–keyboard
1
3
4
2
A
B
SNAP
DISP
DISP
MODEFAST
MUX
NEXT
Q
ON
Q+Q-
3x Q
OFF
LAN
USB
A+ B- P1+ P2+ P3+ P4+
P5a
P6a P7a
S S P1- P2- P3- P4-
P5b
P6b P7b
X2 X3
X_AV
KL11 KL12 KL7KL8 KL9KL10
KL4
X_AR X_BV X_BR
T1A T1B S1 T2A T2B T3A T3B S3 T4B T4A
T1a T1b S1 T2a T2b T3a T3b S3 T4b T4a
N(-)
PE
L(+)
AV AVS AGN ARS AR BV BVS BGN BRS BR
1
2
