14 User modes
14.1 StandardUser mode PIOX S72*
2022-05-15, UMPIOX_S72xV1-9EN
138
User mode selection
• Select the menu item User mode.
• Press ENTER.
• Select a list item.
• Press ENTER.
Special settings
• Select the measuring channel in the program branch Options.
• Press ENTER.
• Select the list item Special settings.
• Press ENTER.
The menu items of the user mode are consecutively displayed.
14.1 StandardUser mode
In the StandardUser mode, all measurements can be carried out for the corresponding application. At the first start-up the
transmitter operates in the StandardUser mode.
14.1.1 Cut-off flow
The cut-off flow is a lower limit for the flow velocity. All measured flow velocities that are below the limit are set to zero.
The cut-off flow can depend on the flow direction.
• Select the menu item Options\Special settings.
• Press ENTER until the menu item Cut-off flow is displayed.
•Select Off if no value is to be entered for the cut-off flow.
•Select Default if no customized inputs are to be made (default: ± 25 mm/s).
•Select Customized to define the values of the cut-off flow for the positive and negative flow direction.
• Press ENTER.
All values of the flow velocity for the positive flow direction below this limit are set to zero.
• Enter the cut-off flow.
• Press ENTER.
All values of the flow velocity for the negative flow direction (as absolute value) below this absolute limit are set to zero.
• Enter the cut-off flow as absolute value.
• Press ENTER.
Special functions\System settings\User mode
Options\Channel\Special settings
Options\Special settings\Cut-off flow
Options\Special settings\+Cut-off flow
Options\Special settings\-Cut-off flow
