14 User modes
PIOX S72*
137
UMPIOX_S72xV1-9EN, 2022-05-15
14 User modes
The user modes allow extended diagnostics of signals and
measured values as well as the definition of additional
parameters adapted to the application.
The following user modes can be selected:
•StandardUser
•ExpertUser
•SuperUser
•SuperUser ext.
Depending on the selected user mode, further options are displayed in the program branch Options\Channel\
Special settings.
Special functions
System settings
User mode
→ StandardUser
→ ExpertUser
→ SuperUser
→ SuperUser ext.
see annex A
Tab. 14.1: Menu items of the user modes
Options\Special settings StandardUser ExpertUser SuperUser SuperUser ext. default
Cut-off flow xxxx On
Flow velocity limit xxx Off
Pig detection xx Off
Turbulence mode xxxx Off
Max. amplification xxx Off
Pipe signal detection xxx On
LWT pipe wall calibr. xx Off
Linear calibration xx Off
Profile correction xxx On
Weighting factor xx Off
Multi-point calibration
(if enabled in Special
functions\Measurement\
Measurement settings)
xxxx
Transducer temp. and Transd.
temp. violat. (as source item
Diagnostic values)
xx
Extended diagnostics
(in the program branch Options,
calculation channels)
xxx
