9 Start-up
9.4 Program branches PIOX S72*
2022-05-15, UMPIOX_S72xV1-9EN
98
9.4 Program branches
The following schema shows the program branches. For a detailed overview of the menu structure see annex A.
9.5 Language
The language of the transmitter can be selected:
• Select the menu item Language.
• Press ENTER.
• Select the desired language from the scroll list.
• Press ENTER.
Afterwards the menu will be displayed in the selected language. The selected language remains activated when the
transmitter is switched off and on again.
The language can also be changed by entering a HotCode.
9.6 Initialization
During an initialization (INIT) of the transmitter, all settings are reset to the factory settings.
Proceed as follows to execute an initialization:
• When switching on a transmitter: keep and C pressed.
• During the operation of the transmitter: press , C and ENTER simultaneously. Release only ENTER. Keep
and C pressed.
During an initialization it is tested whether the key lock is activated. If so, it has to be deactivated.
• Enter a 6-digit key lock code.
• Press ENTER.
If a measurement is currently running, it will be stopped.
Parameters Measurement Options Special functions
Selection of a measuring channel Selection of measuring channels Selection of a measuring channel System settings
Transducer parameters Measuring point number Physical quantity Inputs
Pipe parameters Number of sound paths Units of measurement Current output
Fluid parameters Transducer distance Outputs Measurement
Selection of physical quantity for
analysis
Diagnostic values Input assignment Data logger
Definition of the operating point Transducer positioning Remote functions Snaps
Length of extension cable Measurement Event triggers Communication
Special settings Units of measurement
Field calibration (sound speed) Totalizers
Dialogs/Menus
Parameter record
Libraries
Minimum pipe diameter
Special functions\System settings\Language
