17 Inputs
PIOX S72* 17.1 Configuration of an input
159
UMPIOX_S72xV1-9EN, 2022-05-15
17 Inputs
The inputs are configured in the program branch Special functions and assigned to the individual measuring
channels in the program branch Options.
17.1 Configuration of an input
If the transmitter is equipped with inputs, they have to be
configured.
• Select the program branch Special functions.
•Press ENTER.
• Select the input to be configured.
•Press ENTER.
The scroll list contains all available inputs.
• Select a list item:
– Current Ix (-)
– Voltage Ux (-)
– Binary Bx (-)
– Temperature Tx (-)
If the input has already been configured, it is displayed as follows: Current I1().
Enabling the input
To use the input, it has to be enabled (here: Current I1)
•Select Yes to enable an input or change the settings for an already enabled input.
•Select No to uninstall an already configured input and to return to the previous menu item.
• Press ENTER.
17.1.1 Current and voltage inputs
When configuring the current or voltage inputs, the source item can now be selected and the input and measuring range is
defined.
Selection of the source item
• Select the source item.
Input range
Now the input range is defined.
• Select a list item:
– 0...20 mA
– 4...20 mA
– Other range
• Press ENTER.
If Other range is selected, enter the values Input MIN and Input MAX.
Special functions
Inputs
→ Current Ix
→ Voltage Ux
→ Binary Bx
→ Temperature Tx
see annex A
Special functions\Inputs
Special functions\Inputs\Current I1\I1 Enable
Special functions\Inputs\...\Source item
Special functions\Inputs\...\Input range
