10 Measurement
10.9 Execution of special functions PIOX S72*
2022-05-15, UMPIOX_S72xV1-9EN
126
Channel toggling
If the measurement is started on several channels, the display of the measured values can be adapted as follows:
• Select the list item Channel toggling.
• Press ENTER.
During the measurement, the measured values of channel A or B can be displayed or it is toggled automatically between
these channels.
• Select a list item for channel toggling.
• Press ENTER.
Taking a snap
• Select the list item Take a snap.
• Press ENTER.
A snap will be taken.
This display will only be indicated if snap function is enabled in the menu item Special
functions\Snap\Configuration\Snap.
Reset the event trigger to idle state
• Select the list item Clear alarms.
• Press ENTER.
This display will only be indicated if an event trigger has been parameterized and at least one event trigger has also been
triggered.
Field calibration
• Select the list item Sampling.
• Press ENTER.
The sampling number and the time of sampling are displayed.
display description
Reset totalizers reset the totalizer to zero
Freeze display display the measured value of the totalizer for several seconds
Fehler zurücksetzen reset the totalizer error
Stop/clear totalizers stop totalizer and reset it to zero
Start totalizers start totalizer
Measurement\Execute command\Channel toggling
Measurement\Execute command\Take a snap
Measurement\Execute command\Clear alarms
Measurement\Execute command\Sampling
