20 Advanced functions
20.2 Calculation channels PIOX S72*
2022-05-15, UMPIOX_S72xV1-9EN
176
•Select No limit if the calculation channel has to output all negative values without upper limit
• Press ENTER.
•Select Set to limit if the calculation channel has to output the limit when falling below the upper limit.
• Press ENTER.
•Select Set to error if the calculation channel has to output an error (UNDEF) when falling below the upper limit.
• Press ENTER.
It is possible to define 2 cut-off flows for each calculation channel. They are entered in the unit of measurement of the
physical quantity selected for the calculation channel.
• Enter a value for the positive cut-off flow.
• Press ENTER.
All positive calculated values below the limit are set to zero.
• Enter a value for the negative cut-off flow as absolute value.
• Press ENTER.
All negative calculated values (as absolute value) below the limit are set to zero.
20.2.3 Output options for a calculation channel
• Select the program branch Options.
• Press ENTER.
• Select a calculation channel for which the physical quantity is to be entered.
• Press ENTER.
•Select Measurement.
• Press ENTER.
• Select a physical quantity which is to be transmitted via the calculation channel.
• Press ENTER.
For the selected physical quantity (except sound speed), a scroll list with the available units of measurement is displayed.
The unit of measurement which was selected previously is displayed first.
• Select the unit of measurement of the physical quantity.
• Press ENTER.
• Enter the damping factor.
If the damping factor for the measuring channels A or B has already been entered in the program branch Options, enter
the value zero.
• Press ENTER.
Parameters\Channel Y\Calculation type\-Upper limit
Parameters\Channel Y\Calculation type\+Cut-off flow
Parameters\Channel Y\Calculation type\-Cut-off flow
Options\Channel
Options\Measurement\Physical quantity
Options\Measurement\Damping
